| An elegant new design with ZGSM 3rd-Generation module, more efficient LUMILEDS® LUXEON TX LED luminous source and high reliable MEAN WELL HLG Series LED driver make the ZGSM H series the most cost-effective LED street light available today. |
The new ZGSM H-series LED street lights are utilizing LUMILEDS® LUXEON TX LED luminous source, providing excellent lumen output, long-lasting stability and splendid sight.
Each LUXEON® TX owns eletrostatic protection component, maximally avoid the damage of electrostatic.
More information about the LUXEON® TX and solid-state lighting technologies can be found at |
|
 |
Full Range ZGSM H-series LED street lights Utilizing MEAN WELL® HLG series high-end driver, great luminaire stability, lifespan and optimal performance status.
More information about the MEAN WELL® HLG series and LED driver technologies, please visit |
|
 |
Equipped with exceptional ZGSM 3rd-generation LED module, the brand-new H series LED street light will give best luminous output, stability and super long life. And intend to build the most cost-effective LED street light ever.
ZGSM completed the R&D independently, and reserve all related patents for H-series LED street lights.
Easy assemble/disassemble, neat wiring & connection, up to 110LPW(lumen per watt) luminaire light output, IP66 Rated, 90%+ driver efficiency, 5 year warranty for whole luminaire.
More information about the ZGSM® H series LED street light and LED lighting technologies, please visit |
|
 |
\ n
| |
| Designed for horizontal and vertical applications and 0-15º adjustable by each step. Easily switch 180º of the pole mounting component for horizontal and vertical installation. |
 |
 |
| Specifications |
| Model |
ZGSM-LD280H2 |
| LED Brand |
LUMILEDSLUXEON® TX |
| Driver Brand |
Meanwell HLG series |
| Norminal Wattage |
280W |
| LED Module Quantity |
7 modules |
| Input Voltage |
100-240/277VAC |
| Power Efficiency |
>90% |
| Power Factor |
>0.95 |
| Lamp Rated Luminous Efficiency |
>110lm/w |
| Lamp Rated Lumen output |
30800 lm (Lumen tolerance +/- 5%) |
| Color Rendering Index |
Ra>70 |
| Color Temperature |
4000 or 5000 or 5700K |
| Photometric Type |
Type I Medium;Type II Medium;Type III Medium,TypeV Short |
| Optimal Operating Temperature |
25℃ |
| Storage Temperatures |
-40°C~50°C |
| Working Environment |
Between-40°C~+50°C, 10%~90%RH |
| Total Harmonic Distortion |
< 10% |
| Lumen Maintenance |
> 100000 hours -L70, @25 ºC (77 ºF) |
| Body and Shell Materials |
Anodized Aluminum |
| IP Rating |
IP66 with test report |
| IK Rating |
IK10 with test report |
| Certification |
CE,ROHS,GS,CB, |
| Optional Function |
1-10V DC or PWM Signal or Resistance Dimming |
| Timer/Photocell Control |
| Warranty |
7 years |
| |
| Packing Details |
| Fixture Dimension |
869 x316 x136 mm |
| Fixture Weight |
11.6 kg /25.6 lbs |
| Packing Dimension |
930x370 x200 mm |
| Packing Weight |
13.4 kg /29.5 lbs |
